Gough SnoGuards™ for:
Gough SnoGuards provides a variety of SnoGuard and Snow Rail Systems suitable for any roof! Use Gough
SnoGuards to help protect your family from falling snow and ice and avoid unnecessary roofing
maintenance costs.
Slate
| Product Name |
Application |
Cut Sheet |
Spec Sheet (pdf) |
3-Part Spec (MS Word) |
Installation |
SGAR
 |
For new installation on slate, copper & asphalt shingle. |
 |
|
 |
|
SGAR-SLS
 |
WITH SLOTTED STRAP to hook onto copper nail with any of six positions for retrofit. Distance
from "foot" of snow guard (or bottom of slate) to slots to hook onto nails are: 9", 10", 11
1/4", 12 3/8",13 3/4" and 14 3/4". This snow guard with the slotted strap is the easiest to
retrofit on slate and is less likely to damage slate during installation. Custom lengths are
available. E.g., maybe longer for wood shakes, to accommodate extra long slate or to allow
snow guard to sit farther down or midway down the vertical exposure when using thicker
slate.
|
|
|
|
|
SGAR-STR
 |
WITH HOOKED STRAP to catch top of slate for retrofit.
If you have a random width slate and are concerned about an even, consistent, aesthetic
pattern of the snow guards, the hooked strap will allow you to select your horizontal
position of the snow guard from left to right without being limited to the position of the
copper nail of the slate. However, this can cause more broken slate during installation when
lifting the slate higher to accommodate the extra thickness of the strap's hook. I don't
recommend it, but some have wanted it.
|
|
|
|
|
SGNL
 |
New installation or retrofit. FOR USE WITH GREENSTONE SLATE COMPANY'S NU-LOK SLATE ROOF
SYSTEM
|
|
|
|
|
SGPM
 |
The SGPM is powder coated to a color of your choice. Please indicate what Firestone,
Pac-Clad, AEP-SPAN or DuPont color most closely matches your roof panel color. Or send us a
sample.
|
|
|
|
|
SGP-J
 |
The Plain Jane is actually a SGAR made of Kynar colored aluminum or mill finish aluminum. If
it is in Kynar, it is whatever color we have in stock. Therefore, they are less expensive.
|
|
|
|
|
Tile
| Product Name |
Application |
Cut Sheet |
Spec Sheet |
3-Part Spec (MS Word) |
Installation |
SGSP
 |
FOR NEW & RETROFIT |
|
|
|
|
SGFR
 |
FOR NEW & RETROFIT |
|
|
|
|
SGBK
 |
FOR NEW & RETROFIT |
|
|
|
|
Asphalt
| Product Name |
Application |
Cut Sheet |
Spec Sheet |
3-Part Spec (MS Word) |
Installation |
SGAR
|
For new installation on slate, copper, asphalt shingle, etc |
|
|
|
|
SGPJ
|
For new installation on asphalt shingles. The Plain Jane is actually a SGAR made of Kynar
colored aluminum and comes in whatever color we have in stock. Therefore, they are a little
less expensive.
|
|
|
|
|
SGPM
|
For new installation on asphalt shingle and painted metal roofs. This Gough SnoGuard is
powder coated to a matching color of your choice.
|
|
|
|
|
Copper & Standing Seam
| Product Name |
Application |
Cut Sheet |
Spec Sheet |
3-Part Spec (MS Word) |
Installation |
SGAR
|
For new installation on slate, copper, asphalt shingle, etc If soldering on copper, see
video under "Installation" on left.
|
|
|
|
|
SGPM
|
For painted metal roofs to a color of your choice. (Same as SGAR but is of a powder coated
metal that will not discolor.) Avoids unnecessary metal roof panel penetrations and stains
from steel snow guards. Use metal SnoGuards™ on metal roofs.
|
|
|
|
|
Sure Bond 190
 |
For adhering SnoGuards to Painted Metal Roofs. Best if applied at a minimum of 50 degrees
for a 30-day cure period. (Cooler temperatures will take a longer period of time to cure.) A
winter-grade Sure Bond is available, but does not have the holding strength as the SB 190. 1
Tube Provides Adhesive for approximately 15 Gough SnoGuards.
|
|
|
|
|
Delta-Therm Heat Trace Cables and Controls
| Item |
Item Description |
RFP Form |
Spec Sheet |
|
DTC-24 Control Series
Snow Melting or Roof and Gutter De-icing Control
|
|
|
Cable Clips For The Heat Cable Industry
| Item Picture |
Item Description |
|
DSH - The downspout hanger is used to prevent damage to the deicing cable as it
enters a downspout and to support the deicing cable once inside of the downspout. It can
also protect against other sharp edges.
Use one downspout hanger for each deicing cable entering or exiting the top of the
downspout.
Instructions are included. |
|
CL20 - Roof Clip Bracket (stock) |
|
CL36 - Roof Clip Bracket with larger base for increased holding strength
(stock) |
 |
CL3-AL (stock), no mount holes |
 |
CL3-AL-MH (stock) with mount holes |
 |
CL6-AL (stock), no mount holes |
 |
CL3-CU (stock), no mount holes |
 |
CL3-CU with mount holes (special order) |
 |
CL6-CU without mount holes (stock) |
 |
CL6-CU with mount holes (special order) |
 |
CL3-CU-SLS |
•
